Mercedes-Benz Sprinter

Properties Values
Vendor Mersedes
Model Benz Sprinter

Factory Options:

HIGH ROOF is an option
Vehicle height 2612mm
Load area height 1940mm
Sliding door opening height 1820mm
Barn door opening height 1840mm
Kerb weight 2110kg
Payload 1440kg


Engine Capacity 2.2Litre 2143cc
Engine Type / Cylinders: Inline 4
Fuel Type Diesel
Power 95.0kW @ 3800 rpm
Torque 305Nm @ 1200-2400 rpm
Bore/Stroke 16.2:1
Valves/Valve Desc. 83.0 x 99.0mm
Aspiration 16 / DOHC
Location/Orientation Front / Inline


Transmission 7-speed automatic
Drivetrain Rear-wheel drive

Weights and Capacities

Weight 2080 kg
Towing Capacity 2000 max kg with brakes
Fuel Tank Size 75 litres

Performance / Statistics

Fuel Usage l/100km l/1000km Range
Average 7.7 77 974km
CO2 emissions kg/km kg/1000km kg/range
Average 203 203 197.722
Kerb to kerb 13.4m

Wheels and Tyres

Type Steel
Front Wheels: 6.5/16
Front Tyres: 235/65
Rear Wheels: 6.5/16
Rear Tyres: 235/65
Spare: Full size

Dimensions (Exterior)

Length 5926 mm
Width 2426 mm
Width (without mirrors) 1993 mm
Height 2323
Wheelbase 3665
1240 mm
