Hyundai H1

Properties Values
Vendor Hyundai
Model H1

Doors 5
Body Shape panel van
Engine position/location front
Engine capacity (cc) 2 497
Engine size (litre) 2.5
Engine + detail 2.5 turbo diesel
Cylinder layout inline
Cylinders 4
Cylinder layout + quantity i4
Cam dohc
Valves per cylinder 4
Valves quantity 16
Fuel Type diesel
Turbocharger
Power maximum (kW) 125
Power maximum total (kW) 125
Power peak revs (r/min) 3 800
Power to weight ratio (kW/ton) 58
Torque maximum (Nm) 392
Torque maximum total (Nm) 392
Torque peak revs (r/min) 2 000
Torque to weight ratio (Nm/ton) 181
Fuel consumption urban (l/100km) n/a
Fuel consumption extra urban (l/100km) n/a
Fuel consumption average (l/100km) 9.7
CO2 emissions average (g/km) 257
Fuel range average (km) 773
Acceleration 0-100 kmh (s) 14.9
Maximum top speed (km/h) 180
Driven wheels rear
Driven wheels quantity 2
Gearratios quantity 5
Gearshift automatic
Transmission type automatic
Front tyres 215/70 R16
Reartyres 215/70 R16
Airbag quantity 2
Central locking remote
Cup bottle holders front+rear
Electric windows front
Seats quantity 6
Length (mm) 5 125
Width excl mirrors incl mirrors (mm) 1 920
Height (mm) 1 935
Wheel base (mm) 3 200
Ground clearance minimum maximum (mm) 190
Turning circle wheels body (m) 10.2-11.2
Load volume / capacity (L) 2 500
Load volume: maximum (L) 2 500
Unladen/tare/kerb weight (kg) 2 166
Load carrying capacity / payload 1 100
Gross weight (GVM) 3 242
Towing capacity - unbraked 750
Towing capacity - braked 1 500
Fuel tank capacity (incl reserve) 75
Warranty time (years) 5
Warranty distance (km) 150 000
Service pla
Service plan time (years) 5
Service plan time (distance) 90 000
Roadside assistance time 5
Service interval (distance) 15 000
MMcode 26545530
MMVariant H-1 2.5 CRDi MULTICAB A/T 6 SEAT
MMintrodate 11/1/2011
